b. Press Next to continue.
Note: For help with the Adding a New Implement Wizard, see
“Adding A New Implement” on page
3. Select Planter/Seeder Type and Attachment Method
a. Select the Planter setting (top drop-down menu).
b. Select an appropriate attachment Method (bottom drop-down menu).
c. Press Next to continue.
4. Select Implement Options
a. Under the Planter Monitor drop-down menu, select Seed Monitor Module.
• Split Rows Enabled - Check this box to enable the display to log data from the planter’s Split Row units.
(For split row-enabled planters, you will need to create separate implement configurations for Split
Row and non-Split Row operations).
• Planter Section Row Shutoff - Check the Planter Section Row Shutoff check box if you are using Row
Shutoff.
5. Enter Number of Rows and Spacing
a. Use the up and down arrow keys to enter the number of rows and spacing.
Note: These numbers will vary depending upon the crop that you are planting. For example, corn may require
a 16 row, 30-inch spacing configuration; while soybeans could possibly require a 31 row, 15-inch spacing
configuration.
b. When finished, press Next.
6. Enter Number of Implement Sections
a. Use the up and down arrow keys to enter the number of implement sections.
b. Press Next to continue.
Note: Do not enter the number of individual rows. Enter the number of swath sections that can be
independently turned on and off.
7. Enter Distance from Hitch to Application Point
a. Use the numeric keypad to enter the distance from the implement hitch to the application point (from front to
back).
b. Press Next to continue.
8. Enter Implement Name
a. Use the keyboard button to enter an Implement Name.
b. Press Finish.
9. Select Operation Type
The Operating Configuration Wizard reappears. You must select an operation type.
Select either
- Area Logging (used for a Site Verification operation)
- Rate Logging/Control (used for population control).
