Part No. 2002831-31 Rev. B

1

Tillage Quick Reference Guide

Section 1: Configuration Procedure

The following setup procedure describes how to configure Tillage equipment. To

begin this procedure, to the Configuration Tab in Tillage, press the Add button, and the
Operating Configuration Wizard appears. Follow the instructions below.

Tillage Configuration

STEPS ACTION

1

Select Vehicle

Use the drop down list to select the vehicle you would like to use in this
configuration and proceed to Step 5. If there are no vehicles in the list press the New
button. Press Next to continue.

2

Create New Vehicle

The Vehicle Setup Wizard appears. Select the correct Vehicle Type from the drop-
down list. Press Next to continue.

3

Enter Vehicle Information

Use the keyboard buttons to enter the vehicle's make and model. Press Next to
continue.

4

Enter Vehicle Name

Use the keyboard buttons to enter the vehicle's make and model. Press Finish to
return to the Operating Configuration Wizard.

5

Select Implement

Use the drop down list to select the implement you would like to use in this
configuration and proceed to Step 10 on page 2. If there are no implements in the list
press the New button. Press Next to continue.

6

Select Implement Attachment Method

The Implement Setup Wizard appears. Use the drop down list to select an implement
attachment method. Press Next to continue.

7

Enter Full Swath Width

Use the numeric keypad to enter the full swath width of the implement. Press Next
to continue.

8

Enter Distance from Hitch to Application Point (front to back)

Enter the distance from the hitch to the application point using the numeric keypad.
Press Next to continue.
