105
P
LANTING
I
MPLEMENT
T
AB
I
MPLEMENT
T
AB
S
ETTINGS
Individual implements are set up and configured from the
Implement Tab. The implement list displays all previously set
up implements that are available for use when creating new
configurations.
To see a Planting Configuration Menu that includes
Implement Tab settings, see
“Planting/Seeding Menu Tree” on
page 165 .
• Add button
Press to add a new implement. A wizard will walk you through setting up the implement. For detailed
information, see
“Adding A New Implement” on page 106 .
• Edit Name button
Press to edit the name of a selected implement from the list. The on-screen keyboard will be made available
to make any required edits.
• Remove button
Press to remove a selected implement.
WARNING: When deleting an implement all regions and configurations using it will be deleted!
• Swath Section Offsets button
Press to edit the swath section offsets, distance from tractor hitch to application point, and distance from
front hitch to rear hitch of the implement. An on-screen wizard will walk you through the edit process. For
detailed information see
“Swath Section Offsets” on page 107s .
• Kinze Planter Monitor Setup
Allows the operator to adjust configuration settings for the Planter, Sensor and Alarms. For more
information, see
“KINZE Planter Monitor Setup” on page 133 .
• Configure Clutch Modules button and Enable Seed Clutch Control check box
The Enable Seed Row Shutoff check box allows you to configure a Row Shutoff Module, which is a function
of SeedCommand.
For step-by-step information on configuring the Row Shutoff Modules, see “Row Shutoff
Configuration” on page 119 ; and more specifically, see “Enable Seed Row Shutoff” on page 120.
Note: You must have the Enable Row Shutoff Module check box selected in order to have the Configure Row
Shutoff button enabled.
