122
15. Add Additional Application Equipment (Optional)
The Add Additional Application Equipment window appears. From here, you may add additional
equipment or controllers to your planting configuration so that you may record liquid or dry products. For
example, if you are using DirectCommand to spray a liquid application, or if you are using a serial
controller, you should add this equipment to your configuration at this window.
a. Add equipment by pressing Add and following the Equipment Configuration Wizard
b. Press Next to continue.
Note: If you choose to add additional equipment, add them in the same order as the implements are attached.
Step 16: Select Implement Switch (None)
a. The Select Implement Switch window appears. Choose None.
b. Press Next to continue.
Step 17: Select Ground Speed Source
a. Select your ground speed source. If you will be using GPS as the primary source, you will need to select a
secondary source.
b. Press Next to continue.
Note: If you are not using GPS for ground speed, then after you have created a configuration you must
calibrate the ground speed sensor for accurate speed and area calculations. For more information, see
“Calibrate Distance” on page 100 .
Step 18: Enter Configuration Name
a. A window appears, asking you to enter a suggested configuration name. Use the keypad to enter a name.
b. Press Finish.
Your Row Shutoff Configuration is now complete.
H
YDRAULIC
S
EED
C
ONTROL
C
HECKLIST
The Hydraulic Seed Control Module is an Ag Leader SeedCommand product that allows users to control
up to three hydraulic motor drives via the display. Configure the Hydraulic Seed Rate Control Module in
the following order:
1. Configure Hydraulic Seed Rate Control Module.
See “Hydraulic Seed Control Configuration” on page 123 .
2. Enter Controller Settings
Including the Max Meter Speed, Gear Ratio and Minimum Allowable Ground Speed. See “Hydraulic Seed
Control Configuration” on page 123 , “Hydraulic Seed Controller Settings for Specific Planters ” on page 110
and also “Controller Settings - Auxiliary Tab” on page 112 .
3. Prime the Hydraulic Seed Meter.
See “Seed Meter Prime (Hydraulic Seed Control feature)” on page 152
4. Enter Meter Calibration Number.
This number, representing seeds per revolution, is set according to the number of seeds dropped per one
revolution of the seed meter. See
“Hydraulic Seed Control on Run Screen” on page 149 and also “Hydraulic
Seed Control Seed Meter Calibration Numbers” on page 149 .
5. Perform a Seed Meter Calibration.
A new calibration should be performed if your as-applied seed rate does not match the population found in
the ground. See
“Hydraulic Seed Control Seed Meter Calibration” on page 151 .
