c. Press the Configure Clutch Modules button.
9. Enter number of clutch sections
a. Enter the same number of clutch sections that you specified in Step 4.
b. Press Accept.
Note: If you enter in a different number of clutch sections other than that specified in the earlier implement
configuration, the clutch module configuration will fail. Instead, you will see a message stating that “The
number of detected module outputs does not equal the number of planter sections.”
You will also see this same message if you have not connected the clutches to the module. Thus, check
these connections also.
10. Configuration complete
a. A message window appears, stating “Configuration Complete.”
b. Press OK.
11. Create an Operating Configuration
Now that you have completed the Row Shutoff Configuration, you must now create an operating
configuration.
Go to the Configuration Tab.
a. Press Add.
b. The Operating Configuration Wizard appears. Select a vehicle.
c. Press Next to continue.
12. Select Implement
a. Use the drop-down menu to select an implement.
b. Press Next to continue.
13. Select Area Logging (Site Verification)
a. The Select Operation Type window appears. The window gives you the choice of Rate Logging/Control or
Area Logging (Site Verification).
b. Choose Area Logging (Site Verification).
c. Press Next to continue.
14. Select Planting Method
a. Choose either Single Variety, Two-Variety Split, or Three Variety.
Note: Single Variety records only one variety for the entire planter/seeder. Split Planting allows two or three
varieties to be recorded and mapped simultaneously.
However, the Split Planter Configuration cannot be used for Single Variety planting. If you are planting a single
variety, you must create a Single Variety configuration.
b. Press Next to continue.
Auxiliary Step: Assign Sections to Splits on Planter (if split planter)
a. If you have chosen a Split Planter, then a window appears where you may assign sections to splits on the
planter.
b. Use the numeric keypad to enter in a different number of sections.
Note: Enter the correct number of swath sections for each variety split on the planter.
