193
A
PPLICATION
14. Name Tank Mix
Enter a unique name for the liquid tank mix.
Press Finish to complete the setup process.
15. List Showing Tank Mix Details
Shown at left is the Product Tab showing the new tank as a
selection in the Product List.
Note: Select a product to view the individual components and amounts in the Mix/Blend Information frame.
D
RY
(G
RANULAR
) F
ERTILIZER
B
LEND
S
ETUP
Dry fertilizer blends are set up by using the on-screen wizard described in the following steps. A dry
blend can contain up to seven individual components.
1. Adding A Product Mix
Press the Add button on the product setup screen to display
the dialog at left.
Press the Add Product Mix button to start the process of
creating a dry product blend.
2. Creating A Dry Blend
Select Dry Blend from the list box.
Press NEXT to continue.
3. Base Amount And Units Selection
Enter a Base Amount of product and the controlling Units for
the dry product blend.
Press NEXT to continue.
Note: The Base Amount is the total weight of product for the fertilizer blend. The Base Amount does not need
to match the actual volume of product that will be applied, but is used only to establish the ratio of all products
to the total volume.
4. Start Adding Components
Press the Add button to start the process of adding components to the fertilizer blend.
Note: Any liquid herbicides set up within the display can be added to create an impregnated blend product.
5. Select Component
Select the desired component from the list box. New components can be set up at this time if required.
Press NEXT to continue.
