Troubleshooting direct injection configurations – Ag Leader InSight Ver.8.0 Users Manual User Manual
Page 275
261
A
PPLICATION
T
ROUBLESHOOTING
D
IRECT
I
NJECTION
C
ONFIGURATIONS
When controlling a chemical injection pump using the
Injection Module PN: 4000896 the configuration
requires the use of a Liquid Module PN: 4000394. The
injection control is based off of the vehicle that has
been configured for the liquid DirectCommand control
channel. Once configured, the Injection pump uses the
same switch inputs and ground speed input that has
been configured for the liquid system.
