224
To open the Target Rate window, press the Target Rate button. This button has three grey
chevrons on it, as shown here.
Target Rate Screen - shown for DAP
The Target Rate window will appear for all
target rates being applied; (for instance, Serial
Controllers, Liquid DirectCommand
applications, and Granular DirectCommand
applications).Press this button again when you
wish to return to the Run screen.
Product Application Rate
The Product Application Rate settings, shown at the left of the Target Rate window, lists the Product,
Target Rate, Actual Rate, and Flow Rate of the product.
• Product
The Product lists the name of the product being applied. In the example above, the product applied is DAP.
• Target
The Target Rate is the amount of product that you wish to apply.
Note: In some conditions, the Target Rate may increment more quickly than the Actual Rate.
• Actual
The Flow Sensor returns the actual rate of the product that you are applying.
Note: In some conditions, the Actual Rate may increment slower than the Target Rate, or its numeric values
may vary before matching the Target Rate.
• Flow Rate
The Flow Rate is shown in units per minute.
• Rate Control
The Rate Control buttons, listed below and on the following page, allow you to enter the specific rate
applied.
The Manual Valve Control button allows operators to specify the position of the control valve.
Operators use this option to prime the system before application or clean out equipment at the
end of the day.
Note: The Manual Valve Control setting is only available in DirectCommand. It is not available for serial
configurations.
