140

b. Press FINISH to complete calibration and store the calculated value.

Note: Calibration settings can be manually adjusted if desired by pressing Enter CAL Number and making
small changes to the setting.

Note: To verify the calibration, repeat the previous steps.

KINZE E

DGE

V

AC

C

ALIBRATION

EdgeVac® Calibration window

Customers who have purchased the EdgeVac® seed meters should
perform an EdgeVac Calibration once a year to make sure that it is
correct. Use the numeric keypad to enter the actual value taken from
the hand-held calibration sensor at the seed sensor.

Note: Enter the level of vacuum measured at the row unit. Measurements should be taken with fans on and
seed meter charged.

R

UN

S

CREEN

O

PERATION

R

UN

S

CREEN

B

UTTONS

Planter Run Screen

Before the Run screen can become active, you must go to the
Field button and accept a field, configuration, product, and region.
For detailed information see

“Field Button (While Not Logging)” on

page

144

.

• Field button
Functionality changes based upon the status of the master switch. If the master is off it allows you to change
grower, farm, field, and configuration. If the master status is on it allows you to view field totals. For more
information, see

“Field Button While Logging” on page

145

; and

“Field Button (While Not Logging)” on

page

144

.

• Region button
Allows you to change and name regions of the field.For more information, see

“Region Button” on page

144

.

• System button
Displays diagnostic information about the internal memory of the display, display information, and CAN
module information.
