4. Select Implement.
a. Using the drop down box select the implement you would like to use in this configuration. If there are no
implements in the list, press New.
b. Press Next to continue.
Note: For help with the adding a new implement wizard, see
“Adding A New Implement” on page
.
5. Select Planter/Seeder Type.
a. The Implement Setup Wizard appears. From the top drop-down menu, select Planter or Seeder/Drill.
b. From the bottom drop-down menu, select either Rear Drawbar or Rear 3-Point Hitch.
c. Press Next to continue.
6. Implement Options.
a. Select the following options, depending upon your desired configuration:
• Planter Monitor drop-down menu - Choose None; or choose either the KINZE Planter Monitor
Module or Seed Monitor Module functions.
• Split Rows Enabled – Check this box to enable the display to log data from the planter’s Split Row units.
(For Split Row-enabled planters, you will need to create separate implement configurations for Split
row and non-Split Row operations).
• Planter Section Row Shutoff – Check this box to enable the SeedCommand planter clutches.
b. Press Next to continue.
7. Enter Number of Rows and Spacing.
a. Use the up and down arrow keys to enter the number of implement sections.
b. Press Next to continue.
8. Enter Number of Implement Sections.
a. Use the up and down arrow keys to enter the number of sections that you want to appear on the Planting
Tab on the Run screen. You may enter up to three implement sections (assuming that you did not check
any Implement Options in previous steps.
• If using a one- or two-section split planter, enter two implement sections.
• If using three varieties, choose one or three sections.
b. Press Next to continue.
Note: Do not enter the number of individual rows. Enter the number of swath sections that can be
independently turned on and off.
9. Enter Section Widths from Left to Right.
a. For implements with more than one swath section, the display will default to the appropriate number of equal
width swath sections. In this instance, two equal sections of eight rows.
b. To edit any of the swath values, select the desired section from the list and press the numeric keypad to
enter in a new width.
c. Press Next to continue.
10. Enter Distance from Hitch to Application Point.
a. Enter the distance from the hitch to the application point using the numeric keypad button.
b. Press Next to continue.
11. Enter Implement Name.
a. Use the keyboard button to enter a name for the implement.
b. Press the Finish button to complete the implement setup process and continue with the Operating
Configuration Wizard.
