Grass Valley Kaleido-X v.7.80 - Manual (Page 84)

76
Managing Kaleido-X Systems
Using XEdit Online
2 On the View menu, point to Panes and tabs, and then click Restore default window
settings.
To close XEdit
• On the File menu, click Exit. Alternatively, click the × button in the upper right corner of
the main application window.
Using XEdit Online
When using XEdit in online mode, any changes made are applied and stored directly on the
multiviewer. When using XEdit in offline mode, all changes are stored locally on your PC or
laptop, and the database must be exported to the multiviewer for the changes to take
effect.
When connected to a multiviewer, any change you make to your system’s configuration
takes effect immediately on the multiviewer itself; your local database is not involved. The
online mode is not limited to basic system configuration; changes can also be made to
existing logical sources, rooms, layouts, RCP users, etc.
Connecting to a Multiviewer
To connect to a multiviewer
1 On the Configure menu, click Connect.
The Connect to Multiviewer window appears.
IP addresses for all the multiviewers that are on the same subnet as your PC are
included in the list.
2 If your PC and the multiviewer are on the same subnet, then you can select the IP
address of the multiviewer you wish to connect to from the list. Otherwise type the
appropriate IP address in the box.
3 Click OK.
4 If access control is enabled for this multiviewer, then XEdit prompts you for a password.
Type the password associated with the RCP user “Admin”, and then click Log on.
Note: In the case of a Kaleido-IP, you must work in online mode, at least
once, to obtain the list of programs and elementary streams under each
transport stream.
