175
Kaleido-X
User’s Manual
Configuring Alarm Debouncing
To configure alarm debouncing
1 Connect to the multiviewer you wish to configure, if you wish to apply the changes in
real time (see Connecting to a Multiviewer on page 76).
2 In the main window, click the System tab, and then:
• In the case of a Kaleido-IP, click Calibrations (Kaleido-IP) on the second-level tab
bar, select the appropriate calibration profile in the Tools pane, and then click the
alarm whose debouncing you wish to calibrate in the main pane.
• For all other multiviewer models, click Description/Calibrations on the second-
level tab bar, navigate to the alarm whose debouncing you wish to calibrate, by
expanding the appropriate multiviewer input, one of its Video elements, and then
the alarm-related elements (or the ABT element, and then one of the ABT’s audio
elements).
3 In the Properties pane, under Debouncing, set appropriate values (see page 162 ) for
the Set duration and Clear duration attributes.
Managing Alarm Providers
To add alarm providers to your Kaleido-X system
1 In the main window, click the System tab, and then click Description/Calibrations on
the second-level tab bar.
A hierarchical list representing the current system appears.
2 Click the multiviewer whose alarm providers you wish to define.
3 In the Properties pane, click the Alarm providers list box.
Note: If this step is omitted, then you will need to export the database to
apply the new calibrations to the multiviewer.
