RS-422 Connection Diagram

Kaleido-X (7RU)

Kaleido-X (14RU)

Refer to the “Kaleido-X (7RU) Expansion” chapter in the Kaleido-X (7RU) Hardware
Description & Installation Manual.

RS-422 Connection Diagram

In the case of a Kaleido-X multiviewer, each output card supports one RS-422 port over an
RJ-45 connector. The Kaleido-X16 supports two RS-422 serial inputs over RJ-45 connectors.

Note:

For information on the KMV-3911 multiviewer’s RS-422 interface,

refer to the KMV-3911 Guide to Installation and Operation, available on the
DVD that shipped with your system, and from the Documentation Library
section of Grass Valley’s website.
