335
Kaleido-X
User’s Manual
Assigning an Audio Output to the Remote Control Panel’s AUDIO
MONITORING Button
To assign an audio output to the Remote Control Panel’s AUDIO MONITORING button for
a room
1 In the main window, click the RCP users tab, and then select the room for which you
wish to configure the remote control panel’s AUDIO MONITORING button, from the
rooms hierarchical list.
2 In the Properties pane, click the Audio monitoring output box, and then select the
output used to monitor audio signals, from the list of available outputs.
Enabling the Large Mouse Pointer for a Room
To display a larger pointer on the monitor wall for a room
1 In the main window, click the RCP users tab, and then select the room where you wish
to use a large pointer on the monitor wall.
2 In the Properties pane, select the Use large mouse pointer check box.
.
