467
Kaleido-X
User’s Manual
Kaleido-X16 input options
Kaleido-X16 output options
Kaleido-X16 router options
Dashboard Messages
The following tables explain messages that may appear in the Status dashboard (lower right
corner) and in the Upgrade dashboard (lower left corner), on the Monitor wall. An “x” in the
7RU, 4RU, X16, KMV, or KMX column indicates that the message applies to a specific
multiviewer model, namely:
Option Part No. Feature
3G KXS-X16-3Gbps 3Gbps format license (1/frame)
CC/XDS KXS-X16-CSX CC/subtitling and XDS data license (1/frame)
Dolby E KXS-X16-Dolby Dolby metadata extraction license (1/frame)
Embedded
Audio KXS-X16-HD-EMB HD/SD-SDI embedded audio license (1/frame)
KXS-X16-SD-EMB SD-SDI embedded audio license (1/frame)
Loudness KXS-X16-Loudness Loudness level measurement license (1/frame)
Option Part No. Feature
Display 90-
Degree
Rotation KXS-X16-Rotator-S Rotation license for Kaleido-X16-S
KXS-X16-Rotator-D Rotation license for Kaleido-X16-D
SDI
Monitoring
Output KXS-X16-HDM-S HD-SDI monitoring output for Kaleido-X16-S
KXS-X16-HDM-D HD-SDI monitoring output for Kaleido-X16-D
3D
1
1.After enabling the 3D support option in XAdmin, refresh the current layout or load another one, for
the change to be reflected on the monitor wall.
KXS-X16-3DLA-S Stereoscopic display license (line alternate mode) for
Kaleido-X16-S
KXS-X16-3DLA-D Stereoscopic display license (line alternate mode) for
Kaleido-X16-D
Option Part No. Feature
SDI Router
Output KXS-X16-RTR16x2 Dual router output option (1/frame)
7RU Kaleido-X (7RU) and Kaleido-X (14RU)
4RU Kaleido-X (4RU)
X16 Kaleido-X16
KMV KMV-3901/3911 and Kaleido-XQUAD
KMX Kaleido-MX, Kaleido-MX 4K, and Kaleido-Modular-X
