423
Kaleido-X
User’s Manual
12 In the Layouts tab, create layouts and assign logical sources created in step 11 to
monitors that can display text (e.g., UMD) and alarms (e.g., UMD, video, text alarm).
97 Unused
98 Unused
99 M/E 2 Output 1
100 M/E 2 Output 2
101 M/E 2 Output 3
102 M/E 2 Output 4
103 Unused
104 Unused
105 M/E 3 Output 1
106 M/E 3 Output 2
107 M/E 3 Output 3
108 M/E 3 Output 4
109 Unused
110 Unused
111 Pgm-Pst Output 1
112 Pgm-Pst Output 2
113 Pgm-Pst Output 3
114 Pgm-Pst Output 4
115 Unused
116 Unused
117 DVE 2 Output 1
118 DVE 2 Output 2
119 DVE 2 Output 3
120 DVE 2 Output 4
121 Store 1
122 Store 2
123 Store 3
124 Store 4
125 Store 5
126 Store 6
127 Store 7
128 Store 8
Source IDs Kahuna
