Grass Valley Kaleido-X v.7.80 User Manual
Page 107
99
Kaleido-X
User’s Manual
Sample spreadsheet: Programs, and Transport streams areas
3 Enter the information that will be used to create the logical source associated with this
program:
E
SSM/SFM source
IP address
In the case of a source-specific multicast (SSM) or source-filtered
multicast (SFM) transport stream, enter the source IP address.
F
Protocol
RTP, or UDP.
G
NIC
The network adapter identifier: LAN2
–
LAN5, for a high-bitrate
stream; LAN1, for a low-bitrate stream. The number of network
adapters varies, depending on the Kaleido-IP model (see
In this column...
Enter this information...
H
Index
If your system involves a control panel from which you control
your multiviewer as a router, set a source number for the logical
source associated with this program to be available through the
KX Router logical router, by entering the appropriate number in
this column. Source numbers must be unique.
I
Category
Text in this column can be used to group related logical sources
together, when you sort the sources table in XEdit (see
on page 202). The category text can have up to
200 characters.
J
Name
The name of the logical source. Names are limited to
48 characters. Logical source names that only contain digits and
have decimal positions that are all zeros must be preceded with an
apostrophe in the spreadsheet.
In this column...
Enter this information...
