Kaleido-Modular-X output options
KMV-3901/3911 input options
KMV-3901/3911 output options
CC/XDS KMX-IN-8-OPT-CSX CC/subtitling and XDS data license (8 inputs) for
KMX-3901-IN-8-D
KMX-IN-16-OPT-CSX CC/subtitling and XDS data license (16 inputs)
for KMX-3901-IN-16-D and KMX-3901-IN-16-Q
Dolby E KMX-IN-8-OPT-DOLBY Dolby metadata extraction license (8 inputs) for
KMX-3901-IN-8-D
KMX-IN-16-OPT-DOLBY Dolby metadata extraction license (16 inputs) for
KMX-3901-IN-16-D and KMX-3901-IN-16-Q
1.4K UHD support requires a minimum of 2 licenses: 1 for the prescaler card, and 1 for every KMX-
3901-IN input card connected to the prescaler card.
Option Part No. Feature
Second Head
Activation KMX-OUT-OPT-OP2 Second head output enable license for KMX-
3901-OUT-S
Display
90-Degree
Rotation KMX-OUT-OPT-ROT-S Single head rotation license for KMX-3901-OUT-S
KMX-OUT-OPT-ROT-D Dual head rotation license for KMX-3901-OUT-D
Option Part No. Feature
3G KMV-39N1-8XN-OPT-
3GBPS 3Gbps signal decoding option (8 inputs)
KMV-39N1-4XN-OPT-
3GBPS 3Gbps signal decoding option (4 inputs)
Embedded
Audio KMV-39N1-8XN-OPT-AUD Embedded audio extraction license (8 inputs)
KMV-39N1-4XN-OPT-AUD Embedded audio extraction license (4 inputs)
Additional
Inputs KMV-3911-4X1-OPT-4IN KMV-3911-4x1 additional inputs 5-8 license
Option Part No. Feature
Second Head
Activation KMV-39N1-NX1-OPT-OP2 Output two enabled license
SDI
Monitoring
Output KMV-3911-NX1-OPT-SDI
O/P HD-SDI monitoring output for KMV-3911 (1 SDI
output)
KMV-3911-NX2-OPT-SDI
O/P HD-SDI monitoring output for KMV-3911 (2 SDI
outputs)
Option Part No. Feature
