474
Administration and Servicing
Network Considerations & Port Usage
From iControl to multiviewer
Between multiviewer and remote control panel
The following ports, used for communications to/from RCP-200 and Kaleido-RCP2 control
panels, are open by default on all Kaleido-X systems:
From multiviewer to peripheral devices
Service Port Transport Notes
Java RMI 32768–65535 TCP Remote Method Invocation (client/server
communication). Dynamic Allocation of ports.
Required for communication between client and
Application Server. This range can be restricted to
match specific security requirements. A minimum of
4000 ports should be allocated.
Service Port Transport Notes
RCP2 5120 TCP Used to listen for Kaleido-X discovery packets
10000 TCP For RCP2 protocol
10001 TCP For RCP2 protocol
5120 UDP On multicast 230.8.8.9 for RCP2 protocol
5121 UDP For RCP2 protocol
HTTP 80 TCP Used by the RCP-200 to obtain information
from the multiviewer’s system database
13000 TCP Used by the RCP-200 to control the multiviewer
via the gateway
Service Port Transport Notes
SMTP 25 TCP Simple Mail Transfer Protocol, for e-mail alerts.
Alpermann+Velte
timer system 8851 TCP Used to obtain information from Plura’s
Alpermann+Velte timer systems.
GPI-1501 5100 TCP Used to obtain information from GPI-1501
General Purpose Interface I/O modules.
1
1.See also: From multiviewer to multiviewer , on page 473.
TSL (network) 8910
2
2.Configurable.
TCP Used to obtain information from TSL devices
that use the TSL UMD version 5.0 protocol.
