132
Calibrating the Kaleido-X
Multiviewer Output Calibrations
A hierarchical list representing the current system appears.
2 In the list, expand the multiviewer whose output heads you wish to calibrate.
3 Expand the appropriate output module.
The expanded module will show the output heads. (Depending on the multiviewer
model, other items may also appear.)
4 Select the head you wish to calibrate.
The color saturation adjustment control appears in the Properties pane.
5 Expand the Calibration heading to show the control if it is not visible.
6 Use the slider to adjust the color saturation until you obtain a pleasing presentation of
the video elements on the monitor wall display driven by the selected head.
Alternatively, type a value (between 0 and 100) directly in the Color saturation box.
7 If appropriate, you may copy the settings from this head to every output head in the
system. To apply the color saturation settings globally throughout your system, click
Apply to all.
This has the same effect as selecting every output head one by one, and adjusting the
Color saturation slider to the same value.
Note: All videos on the monitor wall display controlled by the selected
head are adjusted simultaneously.
