300
Creating Layouts
Configuring Subtitling Monitors
11 If you wish to use the subtitling monitor’s background color for source reporting:
a Click the Background color box, and then click the button that appeared at the
end of the box.
b In Colors, select the appropriate level from the Source color level list.
See Configuring color level assignments on page 200, for more information.
c Set the color’s transparency as desired.
d Set the color to be used for sources whose color levels might not be defined, by
clicking the tab that corresponds to the color space you wish to use, and then
choosing the desired color.
e Click OK to close the color picker window.
f In the Properties pane, the name of the selected source-based color level appears
next to the fallback color (and transparency, if used).
12 Change the Default aspect ratio as needed.
This value is used in the absence of aspect ratio information in the DVB or SCTE 27
subtitling stream, when the associated video stream is not decoded. When the video is
decoded, the video signal’s aspect ratio is used, in the absence of aspect ratio
information in the subtitling stream. See
Setting a Video Monitor’s Aspect Ratio on
