Grass Valley Kaleido-X v.7.80 - Manual (Page 345)

337
Kaleido-X
User’s Manual
3 Modify the system-level attributes for this user (user name, description, password) as
needed. See Changing an RCP User’s Name and Password on page 341.
4 On the File menu, click Save.
Assigning Room Layouts to a Kaleido-RCP2 User’s Presets
To assign a room layout to a Kaleido-RCP2 user’s preset button
1 In the main window, click the RCP users tab, and then select the user for whom you
wish to configure the remote control panel’s preset buttons, from under the
appropriate room in the hierarchical list.
2 For each Kaleido-RCP2 preset button, click the corresponding box in the Properties
pane, and then select the appropriate layout from the list.
Note: These system-level attributes are specific to a user, independent of
the room to which the user is assigned.
Notes
• The “Admin” user name cannot be modified.
• An asterisk (*) will appear beside the RCP user in the main window if any of
the user properties are modified. The asterisk will disappear when the
changes are saved.
• The message “Cannot find reference” indicates that a full screen layout, full
screen zone, or layout associated with a Room or RCP user has been
deleted.
Note: If no layout is specified for this user preset, the layout that has been
selected for this preset in the room’s preferences will apply. It will appear in
gray in the Preset [n] box. See
Setting Room Preferences on page 333.
