527
Kaleido-X
User’s Manual
b Type the appropriate bit rate.
c Configure multicast options if needed.
5 Click Apply configuration.
A message appears confirming that the configuration has been applied.
6 Click OK to dismiss the message.
Configuring Virtual Network Adapters on a Kaleido-IP
To add virtual network adapters on a Kaleido-IP
1 Open XAdmin (see Opening XAdmin on page 507).
2 Click System configuration, in the navigation area on the left of the page.
The System Configuration page appears.
Notes
• If the streaming output is meant to feed a Kaleido-IP multiviewer, the
following output resolution / bit rate combinations should ensure good
video quality on the monitor wall:
• 1920
× 1080 at 15000 kbps
• 1280 × 720 at 11000 kbps
• 960 × 540 at 8000 kbps
• 720 × 480 at 8000 kbps
• 720 × 576 at 8000 kbps
• 480 × 270 at 3500 kbps
• In CBR mode, the minimum bit rate is:
• 3500 kbps for MPEG2
• 1500 kbps for H.264
XAdmin does not prevent you from specifying a lower bit rate but the
Kaleido-X software will ignore lower values and enforce the appropriate
minimum listed above.
