Managing Kaleido-X Systems
Configuring the System Representation
5 Select the Source specific multicast (SSM) check box, and then type the IP address
associated with the specific source you wish to monitor in the Source IP address box.
6 If the stream you wish to add is constrained to a virtual LAN, select Virtual LAN
tagging, and then type the appropriate VLAN identifier.
7 Click OK.
The Kaleido-IP establishes a connection with the selected SSM/SFM stream. All
programs that are part of the selected stream, and the elementary streams included in
these programs, automatically appear under the transport stream element in the
System list.
• Verify the protocol you selected. Registering an RTP stream as UDP instead
of RTP may result in the decoded video appearing jerky or accelerated on
the monitor wall.
Note:
In the case of streams that are available from the same multicast
group address and port number, you must enter the source IP address
associated with a stream before you can add the next one.
Note:
VLAN adapter settings must have been previously configured in
XAdmin. See
Configuring Virtual Network Adapters on a Kaleido-IP
page 527, for more information.
Notes (continued)
