Grass Valley Kaleido-X v.7.80 - Manual (Page 194)

186
Configuring Alarms
Publishing Alarms to SNMP Managers
To identify the target SNMP managers
1 In the main window, click the System tab, and then click Description/Calibrations on
the second-level tab bar.
A hierarchical list representing the current system appears.
2 Click the multiviewer whose SNMP trap targets you wish to identify.
3 If your target SNMP managers filter traps based on a specific community string, then
the Properties pane, click the Community box (which contains “public” by default),
and type the appropriate string.
4 Click the Trap targets box.
5 Click the button that appeared at the end of the box
to open the SNMP Configuration window.
The trap targets list shows all trap targets currently
identified for the selected multiviewer.
SNMP Managers that are trap targets for this
multiviewer are identified by their host address and
port number.
6 Add, remove, or modify trap targets as needed, and
then click OK to confirm and apply the changes, or
click Cancel to close the SNMP Configuration
window without saving your changes to the trap targets list.
To add a trap target to the list
1 In the Host address box, type the IP address of the device that has the target SNMP
manager.
2 In the Port box, type the port number through which the SNMP manager will be
accessed.
3 Click Add.
The new trap target is added to the list.
