140
Calibrating the Kaleido-X
Multiviewer Input Calibrations
2 On the Tools tab, select the audio profile whose loudness measurement you would like
to calibrate.
A hierarchical list representing all applicable calibrations for this profile appears in the
main window.
3 Expand the list, and then click Loudness.
Navigating to the loudness calibration in a Kaleido-X16 or Kaleido-X System list
To navigate to the loudness calibration in a Kaleido-X16 or Kaleido-X System list
1 In the main window, click the System tab, and then click the Description/Calibrations
second-level tab.
2 Expand the appropriate input module, then the video input you wish to calibrate, the
Audio programs & loudness element, the Program element you wish to configure
(Program 1, or Program 2), and then click Loudness.
Calibrating Loudness Probe Assignments
Note:
This section applies to Kaleido-X16, and Kaleido-X with second-
generation input cards (KXI-16SV rev. 600 and later, KXI-16HS3, and KXI-
16HSV3). In the case of a Kaleido-IP, all audio programs can be measured
simultaneously.
