435
Kaleido-X
User’s Manual
default output assignments on a Kayenne Video Processor Frame. Refer to the Kayenne
Installation and Service Manual for more details.
7
Assigning Kayenne tallies, input names, and output names to logical sources
The Kayenne contribution tally protocol provides information on up to 96 external sources,
up to 4 eDPM video/key pairs, up to 6 image store outputs, up to 48 programmable
switcher outputs, up to 2 complete operator suites with the associated alternative source
names, and a few more signals from the Kayenne Video Processor Frame. In XEdit’s
Channels/Sources tab, configure logical sources using text sources and system tallies from
the Kayenne’s serial interface. You will find these elements by expanding the filtered system
list that appears in the Tools pane.
To configure your logical sources
1 In the Channels/Sources tab, add the required number of text and alarm levels for your
purposes (see
Creating and Configuring Logical Sources
You may, for example, add one text level to monitor source labels from the Kayenne
switcher, and two alarm levels to monitor Program and Preview tallies.
2 Click a cell that corresponds to the appropriate text level of a logical source.
3 In the filtered System list, navigate to the text element you wish to monitor, and drag it
onto the selected cell.
7.Manuals and Release Notes for all Grass Valley production switchers are available here:
http://www.grassvalley.com/docs/all_switchers.html#manuals
ME A
ME B
ME C
ME D
Output #
Signal
Output #
Signal
Output #
Signal
Output #
Signal
1
Pgm A
13
ME1 A
25
ME2 A
37
ME3 A
2
Pgm B
14
ME1 B
26
ME2 B
38
ME3 B
3
Pgm C
15
ME1 C
27
ME2 C
39
ME3 C
4
Pgm D
16
ME1 D
28
ME2 D
40
ME3 D
5
Pgm pA
17
ME1 pA
29
ME2 pA
41
ME3 pA
6
Pgm p2
18
ME1 p2
30
ME2 p2
42
ME3 p2
7
Aux 1
19
Aux 4
31
Aux 8
43
Aux 14
8
Aux 1
20
Aux 4
32
Aux 9
44
Aux 15
9
Aux 2
21
Aux 5
33
Aux 10
45
Aux 16
10
Aux 2
22
Aux 6
34
Aux 11
46
Aux 17
11
Aux 3
23
Aux 7
35
Aux 12
47
Aux 18
12
Aux 3
24
Sw Pvw
36
Aux 13
48
Aux 19
