226
Setting Up Rooms
Configuring Displays
To change the rotation setting for a display in a room
1 Click the display you wish to configure.
2 Click the Rotation box in the Properties pane.
The rotation presets appear.
3 Select the configuration that matches the way the actual display is mounted in the
physical room: normal, rotated 90 degrees clockwise, rotated 90 degrees
counterclockwise.
4 On the File menu, click Save.
If you already had created layouts for the room associated with the display whose
rotation setting you just changed, you may need to adjust layout elements in these
layouts (see
Creating Layouts on page 231).
Changing a Display’s Position
To change position of a display in a room
1 Click the display whose position you wish to configure.
2 Click the Position box in the Properties pane, then click the button that appears inside
the box.
The Specify Position window appears.
• In the case of a Kaleido-MX or Kaleido-Modular-X system, every time the
orientation of a display has changed in XEdit, the multiviewer
automatically restarts after the room is saved (or, if you were working in
offline mode, once you have exported the database).
Notes (continued)
