475
Kaleido-X
User’s Manual
From peripheral devices to multiviewer
The following ports must be open on peripheral devices (e.g., router controllers):
Router drivers also use default ports:
Between multiviewer and SNMP managers
Port Transport Notes
2000 TCP Used to control the Kaleido-X internal router via the
Snell (Pro-Bel) SW-P-02 protocol
4381 TCP Used to control the Kaleido-X internal router via the
Nevion (Network) protocol
5194 TCP Used to control the Kaleido-X internal router via the
NVISION Ethernet protocol - Compact router protocol.
14000 TCP Used to control the Kaleido-X internal router via the
Snell (Pro-Bel) SW-P-08 protocol
Driver Port Transport Notes
ETL 4000 TCP
GVG 7000 Native 12345 TCP
NVISION Ethernet protocol - Enterprise router 9193 TCP
VikinX Modular 4381 TCP
Quintech 9100 TCP
Sony HKSPC 12345 TCP GVGNP Emulator
Utah RCP-3 5001 TCP SC-4 Ethernet
Snell (Pro-Bel) SW-P-02 2000 TCP
Snell (Pro-Bel) SW-P-08 14000 TCP
Note: This is configurable in XEdit—you can choose any UDP or TCP/IP port
to use for communications between the multiviewer and an external router.
Service Port Transport Notes
SNMP 161 UDP Used for SNMP (Simple Network Management Protocol)
communications between external SNMP managers and a
multiviewer (e.g., sending get, get-next, and set messages
to a multiviewer’s SNMP agent, and receiving the response).
1161 UDP Used for SNMP (Simple Network Management Protocol)
communications between external SNMP managers and a
Kaleido-IP multiviewer (e.g., sending get, get-next, and set
messages to a multiviewer’s SNMP agent, and receiving the
response).
