248
Creating Layouts
Managing Layouts
To add monitors to a layout
1 Drag components from the widget libraries onto the layout, or create custom
components, using the toolbar buttons ( ).
2 Resize, move and configure the monitors until the desired layout is achieved.
For detailed configuration instructions on the different monitor types, see:
• Configuring Video Monitors , on page 255
• Configuring Audio Monitors , on page 271
• Configuring Loudness Monitors , on page 273
• Configuring Time Code Monitors , on page 278
• Configuring Timers , on page 280
• Configuring UMDs , on page 286
• Configuring Alarm Monitors , on page 293
• Configuring Subtitling Monitors , on page 296
• Configuring Metadata Monitors , on page 301
• Configuring V-Chip Monitors , on page 302
• Configuring Clocks , on page 304
• Working with Composite Monitors , on page 308
• Managing Widget Libraries , on page 318
Removing Monitors
To remove a monitor from a layout
• Click the monitor you wish to remove, and then press Delete on your keyboard.
Duplicating Monitors
To duplicate a monitor within a layout
1 Click the monitor you wish to duplicate.
2 On the Edit menu, click Duplicate. Alternatively, press Ctrl+D.
A copy of the monitor is added to the layout.
3 Move the new monitor to the appropriate position on the layout.
4 Press Ctrl+D again, and repeat until the desired number of copies of the monitor are
added to the layout.
The new copies are automatically positioned at intervals matching the relative
positions of the original monitor and its first duplicate.
Note: All open widget libraries appear in the Tools pane. See Widget library
on page 233.
TIP
To remove multiple monitors in a single operation, extend your selection by
using the standard Ctrl+click keyboard shortcut.
