154
Calibrating the Kaleido-X
Multiviewer Input Calibrations
3 In the Properties pane, set the appropriate values for the out-of-network, and in-
network DTMF sequences.
Allowed characters: 0–9, A–D, *, and #.
4 Proceed in the same fashion with DTMF break 2 sequences to DTMF break 8
sequences, as needed, to define the remaining DTMF sequences you wish to monitor.
Calibrating SCTE 35 Event Reporting Duration
When the Kaleido-IP detects a SCTE 35 command in a transport stream, it momentarily
triggers the corresponding alarm. The alarm status returns to normal after a delay, which
you can configure for your specific purposes if needed.
To calibrate SCTE 35 event reporting duration
1 In the main window, click the System tab, and then click the Calibrations (Kaleido-IP)
tab on the second-level tab bar.
2 In the Tools pane, select the SCTE 35 profile you wish to configure.
3 In the main pane, click Splice received, Splice null received, Time signal received, or
Unsupported command received.
