484
Administration and Servicing
Assigning an IP Address to Each Device in your System
4 Use the four control knobs in the ADD TO LIST area to dial in the IP address of the
multiviewer you wish to operate.
The address appears in the TO ADD box.
5 Press the ADD control knob.
The multiviewer’s IP address appears in the LOOKUP LIST area.
6 Press the CONFIG button, located between the two screens on the front of the RCP-200
to end the configuration process and return to normal operation.
Logging on to the RCP-200
To log on to a Kaleido-X room from the RCP-200
1 On an RCP-200 with an active connection to the network, press the LIST button.
All devices, and Kaleido-X rooms, detected by the RCP-200 appear on the left screen.
Kaleido-X rooms are listed in the form [multiviewer name]\[room name].
If a room belongs to a cluster system, its name appears once for each of the member
multiviewers (e.g., if two multiviewers, KX1 and KX2, are configured as a cluster, and
ROOM1 includes displays fed by both multiviewers, then both KX1\ROOM1 and
KX2\ROOM1 will be listed. To determine the one you should select, review the
following:
• Has the RCP user configuration you wish to use been replicated on every member
of the cluster (see Replicating RCP Users Across a Cluster System on page 94)?
• Do you need to control an external router whose configuration is available only
from one or some specific members of the cluster?
Note: In a default system configuration, a multiviewer’s video outputs are
assigned to specific rooms:
• On a Kaleido-X (7RU), the two DVI/VGA outputs from each of the dual-
head output cards A, B, C and D are assigned to ROOM1, ROOM2, ROOM3
and ROOM4 respectively.
• On a Kaleido-X (4RU), the two DVI/VGA outputs from each of the dual-
head output cards A and B are assigned to ROOM1 and ROOM2
respectively.
• On a Kaleido-X (14RU) expansion system, the two DVI/VGA outputs from
each of the dual-head output cards A, B and C of each of Frame A and
Frame B are assigned to ROOM1, ROOM2, ROOM3, ROOM4, ROOM5 and
ROOM6 respectively.
• On a Kaleido-X16-D, the HDMI outputs from each of the output modules
are assigned to ROOMX16.
• On a Kaleido-X16-S, the HDMI output is assigned to ROOMX16.
• On a KMV-3901/3911, Kaleido-XQUAD, or Kaleido-XQUAD-DUAL, the
HDMI outputs are assigned to ROOM1.
• On a Kaleido-IP, the multiviewer outputs are assigned to ROOM.
• On a Kaleido-MX, Kaleido-MX 4K, or Kaleido-Modular-X, the outputs are
assigned to ROOM1.
