472
Administration and Servicing
Network Considerations & Port Usage
Kaleido-IP
In the case of a Kaleido-IP multiviewer, it is possible to add and configure up to 6000 logical
sources without exceeding the network’s bandwidth or the unit’s decoding resources.
10
Refer to the Kaleido-IP video inputs section (under “Supported Input/Output Formats”), in
the Kaleido-X Release Notes, for details on the number of programs and total streaming
bandwidth supported.
The Kaleido-IP multiviewer joins a multicast group only when decoding is required, that is
when a source is being monitored on the wall. In addition, streams that are not decoded are
joined momentarily in a polling manner—one stream at a time—to update the PMT and
PAT information. The Kaleido-IP leaves the multicast group as soon as a change of layout
implies that a different set of streams must be decoded.
However, if your situation involves frequent changes of layout (e.g., loading a new layout to
the monitor wall every minute), then, when you are creating or editing a layout, make sure
to terminate XEdit’s connection to the Kaleido-IP once configuration tasks are completed
(see
Disconnecting from a Multiviewer on page 78).
TCP/UDP Port Usage
The various Kaleido-X services require access to specific ports. In networks where a firewall
is present between device A and device B, the ports used to communicate from device A to
device B must be open on the incoming (external) side of the firewall.
From client to multiviewer
The following ports must be open on the Client (e.g., workstation running XEdit):
10.In the case of a Kaleido-IP X300 model, to support more than 1500 sources, the multiviewer’s RAM must
be upgraded to 24 GB. Refer to the “Kaleido-IP X300 Memory Modules” section, in the Kaleido-X Release
Notes, for installation instructions. The Kaleido-IP X100 is limited to 1500 sources.
Note: All necessary ports are open by default on the multiviewer. There is
no mechanism provided for changing the default settings.
Service Port Transport Notes
HTTPS 443 TCP Used by XAdmin for secure access
HTTP 80 TCP Used by XEdit and XAdmin
5122 TCP Used by XEdit for “keep alive” (heartbeat)
5432 TCP Used by XEdit for export operations
13000 TCP Online connection
13100 TCP Used for calibration data from XEdit
RCP2 5120 TCP Used to listen for Kaleido-X discovery packets
10000 TCP For RCP2 protocol
10001 TCP For RCP2 protocol
5120 UDP On multicast 230.8.8.9 for RCP2 protocol
5121 UDP For RCP2 protocol
