Creating Layouts
Managing Layouts
To select a background image for a layout
1 Click the Layouts tab, and open the layout whose background you wish to set.
2 Click the display background on the layout.
3 In the Properties pane, click the Background image box, under Appearance, and then
click the button that appeared at the end of the box.
The Select Image window appears.
4 If the image you wish to use is not already listed in Select Image, then click the Open
button
to open the Browse Image window. Locate the image, select it, and
then click Open.
The image is imported into the database.
5 In Select image, select the image from the Image selection list, and then click OK.
Note:
The maximum size for each image is 256 KB, and the maximum
overall size (for all images) is 10 MB. The image can be in PNG, GIF, or JPEG
format. Images can be used on multiple layouts and only need to be
imported to the database once.
