Page 315
307
Kaleido-X
User’s Manual
In such cases, if border antialiasing remains enabled, the clock will have a pink
outline on the monitor wall.
5 Define actions associated to this layout element (see
6 On the File menu, click Save.
Inserting a Clock Logo
To insert a clock logo
1 In the Properties pane, click the Logo box, under Appearance.
2 Click the button that appeared at the end of the box.
The Select Image window appears.
3 If the logo you wish to use is not already listed in Select Image, then click the Open
button to open the Browse Image window. Locate the image, select it, and then click
Open.
Notes
• The maximum size for each image is 256 KB, and the maximum overall size
(for all images) is 10 MB. The image can be in PNG, GIF, or JPEG format.
Images can be used on multiple layouts and only need to be imported to
the database once.
• In the case of a cascade system, XEdit must be connected to the
multiviewer that will provide the source for the corresponding clock. A
clock that is not associated with a specific source is displayed by the
system closest to the display.
