113
Kaleido-X
User’s Manual
If you used the XEdit factory default configuration or the sample database for your
multiviewer model (see
Restoring Factory Defaults on page 115), then the appropriate
slots may already be populated with cards.
3 Add or remove cards until the system’s card slots are populated with cards that match
the hardware configuration of your multiviewer. See Emptying card slots , on page 113,
and Populating card slots , on page 114, for details.
4 On the File menu, click Save.
You new system configuration is saved.
Emptying card slots
To empty card slots in a Kaleido-X or Kaleido-MX system representation
1 In the System list, right-click the populated slot you wish to empty.
2 If you wish to empty multiple slots in a single operation, extend your selection by using
the standard Shift+click or Ctrl+click keyboard shortcuts. In this case, XEdit will prompt
you to confirm your intention.
3 Right-click your selection and then click Remove on the menu.
Alternatively click the populated card slot, and then press Delete on your keyboard.
The slots are now empty and the card type does not appear any more next to the slot
name.
Note: Pressing Delete to empty card slots is only supported in the case of a
single-card selection.
Empty slots
Populated slots
