191
Kaleido-X
User’s Manual
Logical sources are automatically created for every program signal found in the
selected transport stream.
4 Repeat until you have added logical sources for every stream you wish to monitor.
5 If your system involves a control panel from which you will control your multiviewer as
a router, then configure source numbers for the KX Router logical router, by typing the
appropriate numbers in the first column (#) under Source info, and using the
incremental copy tool as needed.
6 On the File menu, click Save.
Managing Logical Sources Associated with Programs in a Transport Stream
In the case of a Kaleido-IP system, you may need to add or remove sources, from time to
time, when programs are added or removed from a transport stream.
Adding logical sources for new programs in a transport stream
To add a logical source for a new program in a transport stream
1 Connect XEdit to the Kaleido-IP (see Using XEdit Online on page 76), and then click the
Channels/Sources tab.
Notes
• Under Source info, dynamic and static names resulting from the Name
level assignments are limited to 48 characters and automatically
truncated as needed.
• In the case of a Kaleido-IP system, do not select Activate automatic
sources creation.
• If the case of router sources, if the router is subject to frequent dimension
changes, then you may want to select Activate automatic sources
creation.
