Verifying an RCP-200
To verify that the RCP-200 is functioning normally
• Log on to the appropriate room from the RCP-200 (see Logging on to the RCP-200 on
page 484).
On the RCP-200’s right-hand screen, you should see a thumbnail view of the room
displays in the Room View navigation pane, with one of the displays selected, and a
view of the monitor wall layout as it appears on the selected display.
Verifying an Audio Bridge Terminal
To verify that the ABT is functioning normally
• Inspect the ACTIVITY and front panel LEDs on the unit to make sure there are no error
conditions.
The ACTIVITY indicator is located on the right-hand side of the rear panel. This LED
reports the status of the Ethernet connection as follows:
Two LEDs are visible on the front panel, one for each power supply. When lit, they both
indicate the same status:
When the ABT is powered up, all three LEDs will be orange until the boot sequence is
terminated. This is a visual indicator that the LEDs are functioning properly.
Loading a Layout
If your system was configured prior to shipment, then the designated layout will show up
on all displays. Otherwise, a gray screen will appear with the following message in the
middle:
“No layout has been assigned to this room. Please load a layout.”
Color Board Status
Off No link detected
Green Normal (good link)
Orange Activity
Red Hardware fault
Flashing red Upgrading firmware
Color Board Status
Green Normal
Flashing green Normal, rebooting
Orange Warning
Flashing Orange Warning, rebooting
Red Hardware fault
Flashing red Upgrading firmware
