The Timer Editor window appears.
6 Choose a timer (see Configuring Timers on page 280) from the Timer List.
It is also possible to assign a timer to a timer monitor by dragging an existing logical
source (containing a timer assignment) to the monitor.
7 Click Save.
8 Modify the timer’s Appearance properties as needed.
9 To attach an action to the timer, click the button beside Mouse click.
The Action Editor window appears.
10 Drag an action from the left pane to the middle pane, then specify the action’s behavior
in the right pane.
Note: Each timer monitor is assigned to exactly one timer. Multiple timer
monitors can be assigned to the same timer. Start/stop/reset or mode
changes applied to one monitor affect all other monitors assigned to the
same timer.
