108
Managing Kaleido-X Systems
Configuring the System Representation
5 Repeat this procedure until you have added all required HLS playlists to your system
configuration.
6 On the File menu, click Save. Alternatively, click the Save button on the toolbar.
Changes to the system are saved.
Adding RTSP transport streams
To add an RTSP transport stream
1 In the main window, click the System tab, and then click Description/Calibrations on
the second level tab bar.
2 Expand the System hierarchical list, and then click the appropriate network adapter
element, for the stream you wish to add:
• NETWORK ADAPTER 2 for a high-bitrate stream;
• alternatively, NETWORK ADAPTER 3, 4, 5, or 6, for a high-bitrate stream, in the case
of a four-port or six-port Kaleido-IP model;
• optionally, NETWORK ADAPTER 1 for a low-bitrate stream.
The supported stream types (Multicast, Unicast, HTTP, RTSP) are listed in the Tools
pane.
3 Drag RTSP from the Tools pane onto the network adapter element.
Notes
• The Kaleido-X software supports UTF-8 encoded stream names. The only
characters, which cannot be used in a stream name are: @ / \ ' and ".
• Both HTTP and HTTPS protocols are supported. If HTTPS is used, there
must be a valid certificate for the connection to be established.
• Under the network adapter elements, HLS master playlists and media
playlists are listed in alphabetical order.
Program
Elementary stream (audio)
Elementary stream (video)
Source URL
Media
Master playlist element
playlists
