266
Creating Layouts
Configuring Video Monitors
To configure a video monitor’s border colors for source reporting
1 In the Properties pane, scroll down to the Alarms/Tallies section.
2 Set the border thickness attributes as desired.
3 Click the border color box for an alarm state you want associated with a distinctive
color, based on the monitor’s current source.
4 Click the button that appeared at the end of the box.
5 In Colors, select the appropriate level from the Source color level list. See Configuring
color level assignments on page 200, for more information.
6 Set the color’s transparency as desired.
7 Set the color to be used for sources whose color levels might not be defined, by clicking
the tab that corresponds to the color space you wish to use, and then choosing the
desired color (see
Configuring a Video Monitor’s Alarm Reporting Behavior on
page 264, for more information).
8 Click OK to close the color picker window.
