Grass Valley Kaleido-X v.7.80 User Manual
Page 111
103
Kaleido-X
User’s Manual
stream
1 In the main window, click the System tab, and then click Description/Calibrations on
the second level tab bar.
2 Expand the System hierarchical list, and then click the appropriate network adapter
element, for the stream you wish to add:
• NETWORK ADAPTER 2 for a high-bitrate stream;
• alternatively, NETWORK ADAPTER 3, 4, 5, or 6, for a high-bitrate stream, in the case
of a four-port or six-port Kaleido-IP model;
• optionally, NETWORK ADAPTER 1 for a low-bitrate stream.
The supported stream types (Multicast, Unicast, HTTP, RTSP) are listed in the Tools
pane.
3 Drag Multicast from the Tools pane onto the network adapter.
The Multicast Stream Configuration window appears.
4 In Multicast Stream Configuration, replace the default stream name if desired, select
the appropriate protocol (RTP, UDP), and type the multicast group address and port
number associated with the transport stream you wish to add.
Notes
• The Kaleido-X Software supports UTF-8 encoded stream names. The only
characters, which cannot be used in a stream name are:
@ / \ '
and
"
.
