488
Administration and Servicing
Assigning an IP Address to Each Device in your System
Selecting a room for the Kaleido-RCP2
To select a room for the Kaleido-RCP2
1 Press and hold the ENTER button until the ESC button lights up, to display the
configuration menu.
2 In the ROOM SELECTION display, press ENTER again to get the room list from the
Kaleido-X systems that are currently available on the network.
3 In the room list, select the room you wish to access by pressing the 2 key (to move up in
the list) or the 8 key (to move down the list).
4 When the appropriate room name is highlighted, press ENTER to accept the new
selection.
5 When prompted, log on to the selected room. See Logging on to the Kaleido-RCP2 on
page 489.
Connecting the Kaleido-RCP2 to Other Kaleido-X Systems
The unicast IP feature enables a Kaleido-RCP2 to find up to three Kaleido-X systems on
different subnets and connect to them (via network gateways), while maintaining
connections to Kaleido-X systems in its own subnet.
Note: By default, a multiviewer’s video outputs are assigned to specific
rooms:
• On a Kaleido-X (7RU), the two DVI/VGA outputs from each of the dual-
head output cards A, B, C and D are assigned to ROOM1, ROOM2,
ROOM3 and ROOM4 respectively.
• On a Kaleido-X (4RU), the two DVI/VGA outputs from each of the dual-
head output cards A and B are assigned to ROOM1 and ROOM2
respectively.
• On a Kaleido-X (14RU) expansion system, the two DVI/VGA outputs
from each of the dual-head output cards A, B and C of each of Frame A
and Frame B are assigned to ROOM1, ROOM2, ROOM3, ROOM4, ROOM5
and ROOM6 respectively.
• On a Kaleido-X16-D, the HDMI outputs from each of the output
modules are assigned to ROOMX16.
• On a Kaleido-X16-S, the HDMI output is assigned to ROOMX16.
• On a KMV-3901/3911, Kaleido-XQUAD, or Kaleido-XQUAD-DUAL, the
HDMI outputs are assigned to ROOM1.
• On a Kaleido-IP, the multiviewer outputs are assigned to ROOM.
• On a Kaleido-MX, Kaleido-MX 4K, or Kaleido-Modular-X, the outputs are
assigned to ROOM1.
Notes
• To navigate the Kaleido-RCP2 menu, press the 2 key to move up, or the 8
key to move down.
• There is no need to configure unicast IP addresses for Kaleido-X systems
on the same subnet as the Kaleido-RCP2.
