240
Creating Layouts
Managing Layouts
Loading a Layout on the Monitor Wall
To load the current layout on the monitor wall, directly from XEdit, in online mode
• Click the LOAD button on the toolbar.
The current layout appears on the monitor wall.
Closing Layouts
To close the current layout
• On the File menu, click Close. Alternatively, click the Close button on the toolbar.
Creating Room Layouts
To create a room layout
1 Click the Layouts tab in the main window.
2 On the File menu, click New.
TIP
When you have more than one layout open, you can switch from one to
another by clicking the tabs at the bottom of the window.
