324
Creating Actions
Creating Background Actions
6 Select the action in the middle pane.
7 In the right pane, specify the attributes of the action.
8 Repeat the procedure if you wish to add action items. If multiple actions are specified,
the trigger (e.g., single click on UMD) will cause all of these actions to be executed in
order.
9 When finished, click OK to close the window, and then click the Save button on the
toolbar.
The next time the layout is loaded on the monitor wall, the actions will be available.
Creating Background Actions
Creating a Background Action from the Actions Tab
To create a background action
1 Open XEdit and load the database associated with the multiviewer for which you wish
to create a background action. Alternatively, click Connect on the Configure menu, to
work online (see
Note:
When you click a monitor on the monitor wall, all the actions
associated with the single-click event are triggered. When you double-click
a monitor, all the actions associated with the single-click AND the double-
click events are triggered.
