39
Kaleido-X
User’s Manual
To hide all the dashboards
• Right-click anywhere on the monitor wall, point to Monitor wall on the menu (if you
clicked a layout element), and then click Hide all dashboards to hide the dashboard on
every display in the room.
Loading Layouts
Loading a Layout by Using the Mouse
To load a layout on the monitor wall, by using the mouse
1 Right-click anywhere on the monitor wall, point to Monitor wall (if you clicked a layout
element), and then click Load layout on the menu.
The layout chooser appears.
Note:
Clicking the × button closes the dashboards on every display
monitor in the room if they were displayed automatically.
Note:
When a dashboard is closed while the system is in an error condition,
it will automatically reappear after 60 minutes, or when a new error occurs.
Hide dashboard
Hide all dashboards
Note:
Due to a limitation in XEdit’s support for drag-and-drop operations,
when you first load a new layout on the monitor wall, you may notice that a
monitor’s source or destination assignment is incorrect. Open the layout in
XEdit, click the corresponding monitor, verify the Source and Monitor wall
destination attributes indicated in the Properties pane, and correct them as
needed. See
Assigning Logical Sources or Monitor Wall Destinations to
Load layout
