To change the IP address of the multiviewer from the monitor wall
1 Right-click anywhere on the monitor wall, point to Monitor wall, and then click System
configuration.
The System Configuration window appears.
2 Click the Ethernet tab.
3 Type the required Frame IP address, network mask, and gateway address in the
appropriate boxes.
4 Type the required addresses for all outputs.
5 Click OK.
6 When prompted to restart the system to apply your changes, click Yes.
The new configuration will become effective once the system restart has completed.
