Renesas SH7641 User Manual
Page 974
Section 25 Electrical Characteristics
Rev. 4.00 Sep. 14, 2005 Page 924 of 982
REJ09B0023-0400
B
φ
= 50 MHz
*
Item Symbol
Min.
Max.
Unit
Figure(s)
Write data delay time 1
t
WDD1
—
14
ns
25.13 to 25.21
Write data delay time 2
t
WDD2
—
14
ns
25.27 to 25.30,
25.34 to 25.36
Write data delay time 3
t
WDD3
—
1/2t
cyc
+ 14
ns
25.40
Write enable hold time 1
t
WDH1
1
—
ns
25.13 to 25.21
Write enable hold time 2
t
WDH2
1
—
ns
25.27 to 25.30,
25.34 to 25.36
Write enable hold time 3
t
WDH3
1/2t
cyc
—
ns
25.40
WAIT setup time 1
t
WTS1
1/2t
cyc
+ 8
—
ns
25.14, 25.15,
25.17 to 25.22
WAIT setup time 2
t
WTS2
8
—
ns
25.16
WAIT hold time 1
t
WTH1
1/2t
cyc
+ 4
—
ns
25.14, 25.15,
25.17 to 25.22
WAIT hold time 2
t
WTH2
4
—
ns
25.16
RAS delay time 1
t
RASD1
1
12
ns
25.23 to 25.34,
25.36 to 25.39
RAS delay time 2
t
RASD2
1/2t
cyc
1/2t
cyc
+ 12
ns
25.40, 25.41
CAS delay time 1
t
CASD1
1
12
ns
25.23 to 25.39
CAS delay time 2
t
CASD2
1/2t
cyc
1/2t
cyc
+ 12
ns
25.40, 25.41
DQM delay time 1
t
DQMD1
1
12
ns
25.23 to 25.36
DQM delay time 2
t
DQMD2
1/2t
cyc
1/2t
cyc
+ 12
ns
25.40, 25.41
CKE delay time 1
t
CKED1
1
12
ns
25.38
CKE delay time 2
t
CKED2
1/2t
cyc
1/2t
cyc
+ 12
ns
25.41
AH delay time
t
AHD
1/2t
cyc
1/2t
cyc
+ 12
ns
25.18
Multiplexed address delay time t
MAD
—
12
ns
25.18
Multiplexed address hold time
t
MAH
0
—
ns
25.18
DACK, TEND delay time
t
DACD
—
Refer to
peripheral modules
ns
25.13 to 25.34
FRAME delay time
t
FMD
1
12
ns
25.19
Note: * The maximum value (f
max
) of B
φ (external bus clock) depends on the number of wait
cycles and the system configuration of your board.
