Section 2 CPU
Rev. 4.00 Sep. 14, 2005 Page 60 of 982
REJ09B0023-0400
Instruction Format
Source
Operand Destination
Operand Sample
Instruction
d type
dddd xxxx
15 0
xxxx dddd
dddddddd : GBR
indirect with
displacement
R0 (register direct) MOV.L @(disp,GBR),R0
R0 (register direct) dddddddd: GBR
indirect with
displacement
MOV.L
@R0,@(disp,GBR)
dddddddd :
PC-relative with
displacement
R0 (register direct) MOVA @(disp,PC),R0
dddddddd :
PC-relative
 BF label
d12 type
dddd xxxx
15 0
dddd dddd
dddddddddddd :
PC-relative
 BRA label
(label=disp+PC)
nd8 type
dddd nnnn xxxx
15 0
dddd
dddddddd : PC-
relative with
displacement
nnnn : register
direct
MOV.L @(disp,PC),Rn
i type
i i i i xxxx
15 0
xxxx i i i i
iiiiiiii :
immediate
Indexed GBR
indirect AND.B
#imm,@(R0,GBR)
iiiiiiii :
immediate
R0 (register direct) AND #imm,R0
iiiiiiii :
immediate
 TRAPA #imm
ni type
nnnn i i i i xxxx
15 0
i i i i
iiiiiiii :
immediate
nnnn : register
direct
ADD #imm,Rn
