Section 24 List of Registers
Rev. 4.00 Sep. 14, 2005 Page 894 of 982
REJ09B0023-0400
Register
Abbreviation
Bit
31/23/15/7
Bit
30/22/14/6
Bit
29/21/13/5
Bit
28/20/12/4
Bit
27/19/11/3
Bit
26/18/10/2
Bit
25/17/9/1
Bit
24/16/8/0 Module
PFCR PF15MD2 PF15MD1 PF14MD2 PF14MD1 PF13MD2 PF13MD1 PF12MD2 PF12MD1 PFC
PF11MD2 PF11MD1 PF10MD2 PF10MD1 PF9MD2 PF9MD1 PF8MD2 PF8MD1
PF7MD2 PF7MD1 PF6MD2 PF6MD1 PF5MD2 PF5MD1 PF4MD2 PF4MD1
PF3MD2 PF3MD1 PF2MD2 PF2MD1 PF1MD2 PF1MD1 PF0MD2 PF0MD1
PGCR — — — — PG13MD2 PG13MD1 PG12MD2 PG12MD1
PG11MD2 PG11MD1 PG10MD2 PG10MD1 PG9MD2 PG9MD1 PG8MD2 PG8MD1
PG7MD2 PG7MD1 PG6MD2 PG6MD1 PG5MD2 PG5MD1 PG4MD2 PG4MD1
PG3MD2 PG3MD1 PG2MD2 PG2MD1 PG1MD2 PG1MD1 PG0MD2 PG0MD1
PHCR — — PH14MD2 PH14MD1 PH13MD2 PH13MD1 PH12MD2 PH12MD1
PH11MD2 PH11MD1 PH10MD2 PH10MD1 PH9MD2 PH9MD1 PH8MD2 PH8MD1
PH7MD2 PH7MD1 PH6MD2 PH6MD1 PH5MD2 PH5MD1 PH4MD2 PH4MD1
PH3MD2 PH3MD1 PH2MD2 PH2MD1 PH1MD2 PH1MD1 PH0MD2 PH0MD1
PJCR — — — — — — PJ12MD2 PJ12MD1
PJ11MD2 PJ11MD1 PJ10MD2 PJ10MD1 PJ9MD2 PJ9MD1 PJ8MD2 PJ8MD1
PJ7MD2 PJ7MD1 PJ6MD2 PJ6MD1 PJ5MD2 PJ5MD1 PJ4MD2 PJ4MD1
PJ3MD2 PJ3MD1 PJ2MD2 PJ2MD1 PJ1MD2 PJ1MD1 PJ0MD2 PJ0MD1
PEIOR PE15IOR PE14IOR PE13IOR PE12IOR PE11IOR PE10IOR PE9IOR PE8IOR
PE7IOR PE6IOR PE5IOR PE4IOR PE3IOR PE2IOR PE1IOR PE0IOR
PEMTURWER — — — — — — — —
— — — — — — — MTURWE
PADR — PA14DT PA13DT PA12DT PA11DT PA10DT PA9DT PA8DT PORT
PA7DT PA6DT PA5DT PA4DT PA3DT PA2DT PA1DT PA0DT
PBDR — — — — — — — PB8DT
PB7DT PB6DT PB5DT PB4DT PB3DT PB2DT PB1DT PB0DT
PCDR PC15DT PC14DT PC13DT PC12DT PC11DT PC10DT PC9DT PC8DT
PC7DT PC6DT PC5DT PC4DT PC3DT PC2DT PC1DT PC0DT
PDDR PD15DT PD14DT PD13DT PD12DT PD11DT PD10DT PD9DT PD8DT
PD7DT PD6DT PD5DT PD4DT PD3DT PD2DT PD1DT PD0DT
PEDR PE15DT PE14DT PE13DT PE12DT PE11DT PE10DT PE9DT PE8DT
PE7DT PE6DT PE5DT PE4DT PE3DT PE2DT PE1DT PE0DT
